FEATURE 1
High-Speed Drilling Capability
It uses a 120W MOPA laser and has a fast drilling speed.
Automatic Laser Drilling Machine(Single Laser)
High-Precision Drilling for Advanced IndustriesOur glass laser drilling machine series provides advanced non-contact laser processing solutions for glass fabrication, replacing conventional mechanical drilling to eliminate common drawbacks such as cracking, edge chipping, tool abrasion and low production yield.
Technical Specifications
| Models | Max Cutting Size | Marking position Precision | Marking speed | Laser power | Marking depth |
|---|---|---|---|---|---|
| DS-JD2621 | 2600×2100 | <0.5mm | 1s/standard 3C mark | 15W/20W/25W | 0.1-0.15mm |
| DS-JD3725 | 3700×2500 | <0.5mm | 15W/20W/25W | 0.1-0.15mm | |
| DS-JD4228 | 4200×2800 | <0.5mm | 15W/20W/25W | 0.1-0.15mm | |
| DS-JD5133 | 5100×3300 | <0.5mm | 15W/20W/25W | 0.1-0.15mm | |
| DS-JD6133 | 6100×3300 | <0.5mm | 15W/20W/25W | 0.1-0.15mm |
Why Choose Our Automatic Laser Drilling Machine?
The automatic laser drilling machine is engineered to meet the demands of high-precision manufacturing. It features a robust design that accommodates both single and double laser configurations, allowing for flexibility in drilling applications. This machine is equipped with advanced CO2 or Fiber Laser technology, capable of drilling at speeds of up to 1000 holes per minute, with a precision of ±0.01mm. This ensures that even the most complex drilling patterns are executed with utmost accuracy.
The machine is ideal for industries where precision is paramount, such as electronics, aerospace, and medical devices. It can handle materials with a maximum drilling diameter of 3.0mm, making it suitable for a variety of substrates. The work area of 600mm x 400mm allows for large-scale production, while the machine's power consumption of 5kW ensures it is energy-efficient.
What sets our automatic laser drilling Machine apart is its ability to handle both small and large-scale projects with ease. Its high-speed drilling capabilities make it perfect for mass production, while its precision ensures that each component meets the highest quality standards. This machine is not just a tool; it's a strategic asset for your manufacturing operations.
- Dual lasers mark at the same time, making the coding speed faster.
- Higher coding level (above AIM DPM/B standard).
- Higher marking position accuracy (less than 0.5mm).
- Rich encoded content, including 3C products, customer-customized logos, bar codes, QR codes, Chinese characters, font patterns, etc.
- The code reading accuracy rate is high At a moving speed of 40-50 meters per minute, the reading rate is 99.9%.
- The coding position can be set by yourself, which is convenient for insulating pairing.
- The product is permanently traceable and has anti-counterfeiting functions.
