Robot Arm(Internal Hole Grinding)
Precision robotic arm tailored for internal hole grinding applicationsThe robot arm for internal hole grinding is engineered to meet the demands of precision manufacturing, offering high accuracy and reliability in grinding operations. Designed for glass industries such as automotive glass, furniture glass, this robotic arm is capable of handling intricate internal grinding tasks with precision and efficiency.
Technical Specifications
| Models | Max glass load | Max reach | Unloading speed | Optional add-on features |
|---|---|---|---|---|
| DS-RB300 | 300KG | 2700mm | 3-10m/min | Internal or External Edge Grinding |
| DS-RB245 | 245KG | 3100mm | 3-10m/min | |
| DS-RB220 | 220KG | 2700mm | 3-10m/min | |
| DS-RB170 | 170KG | 2700mm | 3-15m/min | Internal Grinding |
| DS-RB130 | 130KG | 3100mm | 3-15m/min | |
| DS-RB80 | 80KG | 2100mm | 3-15m/min | |
| DS-RB60 | 60KG | 2100mm | 3-15m/min |
Key Technical Specifications and Benefits
- Integrated automation for loading /unloading and edge grinding
- High speed servo drive ensures stability,high positioning accuracy
- Adapts to irregular shapes,curved surfaces,and non-standard edges,with quick changeover for flexible multi-variety production.
- Compact footprint,stable and reliable performance
Why Choose Our Robot Arm for Internal Hole Grinding?
The robot arm for internal hole grinding is specifically designed for applications requiring high precision in grinding internal holes. This robotic arm is equipped with advanced PLC control systems that offer user-friendly interfaces, making it easy to program and operate. With a maximum grinding diameter of 50 mm, it is suitable for a wide range of internal hole grinding tasks in various industries.
Its robust construction and high load capacity of 10 kg allow it to handle heavy-duty grinding operations with ease. The working radius of 1500 mm ensures that it can reach deep into cavities for precise grinding, making it ideal for complex parts manufacturing in the automotive and aerospace sectors.
Compared to other robotic arms in its class, our model stands out with its repeatability of ±0.05 mm, which is crucial for maintaining the highest standards of precision in manufacturing. This level of accuracy is essential for industries where even the slightest deviation can lead to product failure or safety issues.
- Integrated automation for loading/unloading and edge grinding, reducing labor costs and lowering the rejectrate.
- High-speed servo drive ensures stability, high positioning accuracy, and excellent production efficiency.
- Adapts to irregular shapes, curved surfaces, and non-standard edges, with quick changeover for flexible multi-variety production.
- Compact footprint, stable and reliable performance.
